TA2P Series
AED 0.00
Brand: TiMOTION -TAIWAN
Industrial Motion Both the TA2 and the TA2P are compact, robust, and capable of performing well in certain outdoor environments. A more powerful motor makes the TA2P capable of handling load ratings up to 3500N (787 pounds) while retaining its compact size. In addition to the high power motor, the TA2P linear actuator is available with multiple choices for feedback sensors. Industry certifications for the TA2P linear actuator include IEC / ES 60601-1 and UL73.
NOTE: No Exchange No Return Learn More
Warranty: 1 year from the delivery date, covering manufacturing defects. It does not cover breakage or misuse.
Quality is our priority. Our laboratory equipment is built for precision, durability, and dependable performance, ensuring consistent, reliable support for all your scientific needs.
Available on backorder
General Features
Max. load: 3,500N (push) 2,000N (pull)
Max. speed at max. load: 2.4mm/s
Max. speed at no load: 56.5mm/s
Retracted length: ≥ Stroke + 108mm (with Hall sensors or without output signals)
IP rating: IP66D
Certificate: IEC60601-1, ES60601-1, EN 61000-6-1, EN 61000-6-3, UL73
Stroke: 20~1000mm
Options: POT, Reed or Hall sensors
Voltage: 12/24/36V DC; 12/24V DC (PTC)
Color: Silver
Operational temperature range: -25°C ~ +65°C
Operational temperature range at full performance: +5°C ~ +45°C
Dimension without Sensor or with Hall Sensors (mm)
Dimension with POT or Reed Sensor (mm)
