AELAB Rotary Vacuum Evaporator Vertical

+ 5L heating bath with a wide temperature range (room temp.to180°C), independent temperature control,make it can be used separately.

+ Water/oil heating mode can be changed only through a switch.

+ Manual lift combined with auxiliary lift for precise positioning of the glassware.

+ PID control ensures high temperature accuracy at ±1C (water).

+ Overheating protection temperature at 220°C Boil-dry protection, automatically power off if heating without water/oil in the heating bath.

+ Speed range from 20 to 200rpm, timing interval operation in clockwise and anticlockwise directions for drying process.

+ Patented condenser (cooling surface 1200/1700cm² for selection), double helix condensing tube +center circular arc design to speed up the flow rate of liquid with excellent cooling effect.

+ Ejection mechanism ensures easy exchange of evaporating flask Adjustable immersion angle

+ Patented double spring sealing ring which is made of PTFE provides an excellent sealing performance

+ Remote function provides PC control and data transmission.

+ Compatible with the entire range of AE-RE2 glassware.
