LED Display                                  Waterproof Socket
LED display(not including PCR-1000, Â Â Â Â Â Â Â Â Â Â Â Â Â Â 2 waterproof sockets are located in the back wall,
PCR-1000’s display is LED) Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â for optimum convenience of using small devices inside
the cabinet.
           Â
UV Lamp                                 Side Glass Window
Emission of 253.7 nanometers for most           Side glass windows maximize light and visibility
efficient decontamination. Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â inside the cabinet, providing a bright and open
working environment.
Shelf with IV bar   Â
Air Pattern
ADVANTAGE:
1. LED display(LED display for PCR1000).
2. UV sterilization system.
3. HEPA filter efficiency 99.999% at 0.3μm.
4. Interlock function: UV lamp only can be switched on when the front window is closed, ensuring operator safety.
5. UV timer (0-90 minutes): When the setting time expires, the UV lamp automatically switches off in preparation
for the next experiment.
TECHNICALÂ PARAMETERS:
Model |
PCR-800 |
PCR-1000 |
PCR-1200 |
PCR-1300 |
PCR-1500 |
External Size (W*D*H) |
800*700 *1770mm |
1000*705 *1770mm |
1200*700 *1770mm |
1300*700 *1770mm |
1500*700 *1770mm |
Internal Size (W*D*H) |
700*595 *550mm |
900*595 *560mm |
1100*595 *550mm |
1200*595 *550mm |
1400*595 *550mm |
Work Surface Height |
750mm |
||||
Material |
Main Body: Cold-rolled steel with anti-bacteria powder coating |
||||
Work Table: 304 stainless steel |
|||||
Front & Side Windows |
5mm toughened glass , anti-UV |
||||
Motorized |
Manual |
Motorized |
Motorized |
Motorized |
|
Max Opening |
300mm |
320mm |
300mm |
300mm |
300mm |
Pre-Filter |
Polyester fiber, Washable |
||||
HEPAÂ Filter |
99.999% efficiency at 0.3μm. |
||||
Airflow Velocity |
0.3-0.5m/s, speed adjustable |
||||
Noise |
≤65dB |
||||
UVÂ Lamp |
20W*1 |
20W*2 |
30W*1 |
30W*1 |
40W*1 |
Emission of 253.7 nanometers, with UV timer |
|||||
Illumination Lamp |
LED 8W*2 |
40W*1 |
LED 12W*2 |
||
Illumination |
≥1000Lux |
||||
Shelf with IV bar |
Stainless steel, 502*150*50mm (W*D*H) |
||||
caster |
Universal caster with leveling feet |
||||
Consumption |
400W |
300W |
600W |
600W |
600W |
Waterproof Socket |
Two, total load≤500W |
||||
Power Supply |
AC 220V±10%, 50/60Hz;110V±10%,60Hz |
||||
Standard Accessory |
UV lamp, Fluorescent lamp, Base stand, Waterproof socket*2, Shelf with IV bar |
||||
Gross Weight |
168kg |
178kg |
220kg |
231kg |
250kg |
Package Size (W*D*H) |
960*940 *1450mm |
1150*930 *1450mm |
1350*930 *1450mm |
1450*930 *1450mm |
1650*930 *1450mm
|
Standard Accessory:
UV lamp1pcs
Fluorescent lamp1pc
Base stand1pc
Waterproof socket2pc
Shelf with IV bar1pc
